Semi Automatic 200L Barrel Lobe Pump Capping Sealing Packaging Specialized Liquid Bottling Weighing Filling Machine

filling accuracy : ±3%

packaging material : Plastic, Metal, Wood

Weight (kg) : 200

automatic grade : Semi-Automatic

Price : $3,500-3,800 / set

application : Beverage, Chemical, Water, Other

warranty : 1 Year

core components : Motor, PLC, Pump

Keywords : Fillng Machine

Control : PLC+ Touch Screen

Suitable for : Fluid Material (alll Liquid Products)

MOQ : 1 set

Voltage : 220 V, 110 V, 415V, 380 V

After-sales Service Provided : Video Technical Support

video outgoing-inspection : Provided

machinery test report : Provided

filling nozzle : 4

Filling Volume : 50ml-20L, 50ml-20L

After Warranty Service : Online Suppot

Material : SUS304 / 316

packaging type : Bottles, Cans, Barrel, Pouch

Bottle type : PET Plastic Bottle Glass Bottle

Place of Origin : Shandong, China

dimension(l*w*h) : 1600*600*1800

key selling points : Easy To Operate, Competitive Price, Digital

driven type : Electric

Filling speed : 400-600BPH

filling material : Liquor, Oil, Viscous Liquid, Ketchup, JAM, Glue

Product name : Semi Automatic Liquid Filling Machine

Filling head : 1-6 Heads(Customizable)

Contact Now

Semi Automatic 200L Barrel Lobe Pump Capping Sealing Packaging Specialized Liquid Bottling Weighing Filling Machine

Products Description

Semi-Automatic Pump-Type Weighing Filler.Ideal for liquids, viscous fluids, and pastes, it uses an adjustable pump to transfer materials. Equipped with high-accuracy sensors, it stops filling automatically when reaching the preset weight, ensuring minimal errors. Semi-automatic operation: operators manually place containers, while filling and weighing run automatically. Suitable for small-to-medium production in food, cosmetics, and chemicals. Easy to use and versatile.

Product Paramenters

No.	Item	JTFWB-1
1	Filling nozzles	1
2	Production capacity	200~400bph
3	Filling principle	Pumb filling
4	Filling standard	Depend on customer
5	Bottle height	100~350mm,can customized as required
6	Power	0.37/0.55Kw
7	Frame Material	SUS304
8	Overall dimension(LWH)	customized as required
